Robot Series KBR 100 - 150 - 200 - 250 multi purpose

Basic Functions

Cooking - Drying - Smoking - Roasting

Main features

Temperature up to 160 °C (steam 120 °C)
Suitable for all kind of smoke methods
Closed smoke system CSS (option)
Vertical airflow
Relative humidity control
Water drain integrated in floor
Doors with 2 opening positions
Automatic door opening
Automatic build-in shower
Automatic build-in CIP
Automatic water level control
Full stainless steel heavy construction
High quality insulation
Integrated rid-in system ( No ramps)
Computer controlled
Prepared for registration system

Total electric consumption by

  Unit 4-trolleys 6 trolleys 8 trolleys 10 trolleys
Electric heated kW 84 118,5 158 198
Gas heated kW 9 10,5 14 18
High pressure steam kg/h 9 10,5 14 18

Dimensions

Dimensions outside Unit 4-trolleys 6 trolleys 8 trolleys 10 trolleys
Length mm 2470 3570 4670 5770
Width mm 2996 2996 2996 2996
Height (excl. technical fittings) mm 2990 2990 2990 2990
Height (incl. technical fittings) mm 4685 4685 4685 4685
Recommended room height mm 5700 5700 5700 5700
Extra length by walkthrough execution mm 100 100 100 100

Dimensions inside


Length mm 2154 3254 4354 5454
Width mm 2876 2876 2876 2876
Height mm 2020 2020 2020 2020

Doorway dimensions


Width mm 1200 1200 1200 1200
Height mm 2020 2020 2020 2020

Technical data

  Unit 4-trolleys 6 trolleys 8 trolleys 10 trolleys
Electrical kW 9 10,5 14 18
Compressed air ( 6 bar) m³/h 2,5 2,5 2,5 2,5
Water consumption showering (3 bar) m³/h 4,3 6,6 8,8 11
Water consumption CIP (3 bar) m³/h 4,3 6,6 8,8 11
process air intake Ø mm 300 350 350 400
Process air outlet Ø mm 300 350 350 400
Flue (only gas heated) Ø mm 300 300 300 300
Pressure relief valve (only by steam) Ø mm 50 100 100 100
Computer control MIC 2420 2420 2420 2420

Heating systems

  Unit 4-trolleys 6 trolleys 8 trolleys 10 trolleys
Heating capacity kcal 97000 108000 118800 128800
Electric kW 75 108 144 180
Burner (natural- and liquid gas kW 120 180 240 300
High pressure steam (6 bar) kg/h 180 (NW25) 200 (NW25) 220 (NW32) 240 (NW32)
Oil kg/h 9,7 10,8 11,9 13

Humidity by

  Unit 4-trolleys 6 trolleys 8 trolleys 10 trolleys
Low presure steam by cooking (0,5 bar) kg/h 150 (NW32) 180 (NW40) 220 (NW40) 260 (NW40)
Water injection by cocking  (3 bar) ltr/h 85 105 125 145
